摘要: 為解決現實場景下無人機目標被部分遮擋，導致不易檢測問題，本文提出了基于YOLOX-S改進的反無人機系統目標檢測算法YOLOX-drone。首先，建立無人機圖像數據集；其次，搭建YOLOX-S目標檢測網絡，在此基礎上引入坐標注意力機制，來增強無人機的目標圖像顯著度，突出有用特征抑制無用特征；然后，再去除特征融合層中自下而上的路徑增強結構，減少網絡復雜度，并設計了自適應特征融合網絡結構，增強有用特征的表達能力，抑制干擾，提升檢測精度。在DUT-Anti-UAV數據集上的測試結果表明：YOLOX-drone與YOLOX-S、YOLOv5-S和YOLOX-tiny相比，平均準確率(IoU=0.5)提升了3.2%、4.7%和10.1%；在自建的無人機圖像數據集上的測試結果表明：YOLOX-drone與原YOLOX-S目標檢測模型相比，在無遮擋、一般遮擋、嚴重遮擋情況下，平均準確率(IoU=0.5)分別提高了2.4%、2.1%和6.4%，驗證了改進的算法具有良好的抗遮擋檢測能力。Abstract: With the development and advancement of science and technology, the development and innovation of unmanned aerial vehicle (UAV) technology and products have brought great convenience to people in the fields of aerial photography, plant protection, electric cruise, and so on, but the development of UAVs also brings a series of management problems. Therefore, as a key part of the anti-UAV system, research into effective UAV detection is a pressing issue that must be addressed. In public environments such as parks, stadiums, and schools, the detection and tracking of UAV targets become more difficult due to their inherent characteristics and environmental factors. For example, under the occlusion of background interferences such as trees, buildings, and light, the target detection algorithm is unable to extract the effective features of the UAV target, resulting in target detection failure. It is of great significance to study the anti-occlusion target detection and tracking algorithm of anti-UAV systems for situations where UAVs cannot be successfully detected due to occlusion. This study proposes an improved anti-UAV system target detection algorithm YOLOX-drone based on YOLOX-S to solve the problem of the UAV being deformed and partially occluded in complex scenes, which makes it difficult to identify. First, in this study, numerous occluded drone images are collected in complex scenes, and the drone pictures are downloaded online for occlusion processing. The drone images were labeled to establish a UAV image dataset. Second, the YOLOX-S target detection network was constructed. On this premise, the coordinate attention mechanism is introduced to improve the saliency of the target image when the drone is obscured by highlighting useful features and suppressing useless ones. Then, the bottom-up path enhancement structure in the feature fusion layer is removed to reduce the network complexity, and an adaptive feature fusion network structure is designed to improve the expression ability of useful features, suppress interference, and improve detection accuracy. First, experiments were conducted on the Dalian University of Technology Anti-UAV dataset, and the experimental results show that YOLOX-drone improved average accuracy (IOU = 0.5) by 3.2%, 4.7%, and 10.1% compared to YOLOX-S, YOLOv5-S, and YOLOX-tiny, respectively. Then, experiments were conducted on the self-built UAV image dataset, and YOLOX-drone improved the average accuracy (IOU = 0.5) by 2.4%, 2.1%, and 6.4% in the cases of no occlusion, general occlusion, and severe occlusion, respectively, when compared with the original YOLOX-S target detection model. This demonstrates that the improved algorithm has good anti-occlusion detection ability.
-
Key words:
- anti-drone system /
- target detection /
- occlusion /
- attention mechanism /
- adaptive feature fusion
-
圖 9 改進前后CAM可視化圖. (a)原圖; (b)未加CA注意力機制; (c)加入CA注意力機制
Figure 9. CAM visualization results before and after improvement: (a) original picture; (b) no coordinate attention mechanism; (c) add coordinate attention mechanism
圖 10 特征融合層改進前后檢測結果對比圖. (a) YOLOX-S檢測結果; (b) YOLOX(FPN+ASCFM)檢測結果
Figure 10. Performance comparison before and after improvement of feature fusion layer: (a) YOLOX-S test results; (b) YOLOX (FPN + ASCFM) test results
圖 11 YOLOX-S與YOLOX-drone檢測結果對比圖. (a) YOLOX-S檢測結果; (b) YOLOX-drone檢測結果
Figure 11. Comparison of YOLOX-S and YOLOX-drone test results: (a) YOLOX-S test results; (b) YOLOX-drone test results
表 1 特征圖縮放表
Table 1. Feature map scaling table
Feature map Scale_0 Scale_1 Scale_2 X0 — Up sample(s=2) Up sample(s=4) X1 Down sample(s=2) — Up sample(s=2) X2 Down sample(s=4) Down sample(s=2) —
下載: 導出CSV
表 2 實驗條件設置表
Table 2. Experimental condition setting table
N(No occlusion) R(Reasonable) HO(Heavy occlusion) v=0 v$ \in $(0, 0.35] v$ \in $(0.35,0.6]
下載: 導出CSV
表 3 引入不同注意力機制檢測性能對比表/mAP@0.5
Table 3. Comparison table of detection performance with different attention mechanisms/mAP@0.5
% Model N R HO N+R+HO YOLOX-S 89.3 82.8 58.1 77.5 +SE 89.6 83.5 61.2 79.1 +ECA 89.9 83.2 61.0 79.1 +CBAM 90.0 83.3 61.6 79.8 +CA 91.4 83.8 61.7 80.1
下載: 導出CSV
表 4 YOLOX-S采用不同特征融合層檢測性能對比表mAP@0.5
Table 4. YOLOX-S using different feature fusion layer detection performance comparison table/mAP@0.5
% Feature fusion method N R HO N+R+HO PANet 89.3 82.8 58.1 77.5 FPN 89.6 83.2 60.4 78.5 ASCFM 90.4 84.3 64.3 80.5 PANet+ASCFM 89.9 84.9 62.6 80.3 FPN+ASCFM 90.8 84.9 64.4 80.8
下載: 導出CSV
表 5 ASCFM模塊消融實驗表/mAP@0.5
Table 5. ASCFM module ablation experiment table/mAP@0.5
% Feature fusion method N R HO N+R+HO FPN 89.6 83.2 60.4 78.5 FPN+ASFM 89.6 83.4 61.9 79.5 FPN+ACFM 89.9 84.8 62.6 80.0 FPN+ASCFM 90.8 84.9 64.4 80.8
下載: 導出CSV
表 6 各個模塊逐步添加模型檢測性能表/mAP@0.5
Table 6. Step-by-step addition of model checking performance tables for each module/mAP@0.5
% FPN ASCFM CA N R HO N+R+HO 89.3 82.8 58.1 77.5 √ 89.6 83.2 60.4 78.5 √ √ 90.8 84.9 64.4 80.8 √ √ √ 91.7 84.9 64.5 81.3
下載: 導出CSV
表 7 改進前后網絡復雜性對比表
Table 7. Comparison table of network complexity before and after improvement
Model Params(M) Gflops Times/ms YOLOX-S 8.94 26.64 16.67 YOLOX-drone 10.82 29.91 20.41
下載: 導出CSV
中文字幕在线观看表 8 經典檢測算法檢測性能對比表
Table 8. Classical detection algorithm detection performance comparison table
Model Params(M) Gflops mAP@0.5/% Times/ms YOLOX-tiny 5.03 6.40 83.3 3.94 YOLOv5-S 7.01 15.80 88.7 13.00 YOLOX-S 8.94 26.64 90.2 16.67 YOLOX-drone 10.82 29.91 93.4 20.41
下載: 導出CSV
-
