時效對Al?2Li二元合金鈍化膜耐蝕性及結構的影響

王赫男; 鄧佳誠; 邵冰冰; 劉紅

doi:10.13374/j.issn2095-9389.2018.11.30.004

時效對Al?2Li二元合金鈍化膜耐蝕性及結構的影響

doi: 10.13374/j.issn2095-9389.2018.11.30.004

沈陽航空航天大學材料科學與工程學院，沈陽 110136

基金項目: 國家自然科學基金青年基金資助項目（51301113）；遼寧省自然科學基金資助項目（20170540687）

詳細信息

通訊作者:
E-mail：15042098@qq.com

中圖分類號: TG174.3
計量
- 文章訪問數: 1046
- HTML全文瀏覽量: 751
- PDF下載量: 33
- 被引次數: 0
出版歷程
- 收稿日期: 2018-11-30
- 刊出日期: 2019-11-01

Influence of aging on corrosion resistance and structure of the passive film formed on Al?2Li binary alloys

School of Materials Science and Engineering, Shenyang Aerospace University, Shenyang 110316, China

More Information

Corresponding author: E-mail: 15042098@qq.com

摘要

摘要: Al?Li合金具有低密度、高強韌性和低的腐蝕疲勞擴展速率的優點，在航空領域有著廣泛應用。Al₃Li（δ′）相是Al?Li合金中主要強化相之一，因含有活性元素Li對該合金的腐蝕行為產生顯著影響。為明確δ′相在Al?Li合金電化學腐蝕中的作用，真空熔煉制備Al?2Li二元合金，固溶后進行180 ℃等溫時效，用X射線衍射（XRD）檢測合金的相組成。在質量分數為3.5% 的NaCl水溶液中，用動電位極化的方法測量了該合金的極化曲線。?0.85 V vs SCE鈍化電位下形成鈍化膜后，用電化學阻抗（EIS）檢驗鈍化膜的耐蝕性；用恒電位陽極極化和Mott?Schottky（M?S）曲線對該合金鈍化膜的結構進行分析。結果表明，Al?2Li合金的自腐蝕電位隨時效時間增加先正移后負移；固溶和時效合金鈍化膜的EIS都由兩個容抗弧組成，時效未改變鈍化膜的腐蝕機制；鈍化膜耐蝕性由高到低的順序為：時效20 h>固溶>時效40 h>時效1 h，且耐蝕性與其致密性及膜內的載流子密度有關。
- Al?2Li二元合金 /
- 時效 /
- 鈍化膜 /
- 耐蝕性 /
- 結構
Abstract: Al?Li alloys have the advantage of low density, high strength and toughness, and low corrosion fatigue rate. This combination of properties has led to their use in aerospace. Al₃Li（δ′）phase is one of main strengthening phases of Al?Li alloys. The higher chemical reactivity of Li clearly influences its corrosion behavior. In order to explain the effect of δ′ phase in the Al?Li alloy electrochemical corrosion process, an Al?2Li binary alloy was prepared by vacuum melting. Aging treatment of Al?2Li alloy at 180 ℃ followed by solution treatment were carried out. A potentiodynamic polarization plot of the alloy was tested in a 3.5% (mass fraction) NaCl solution. Phase composition of all samples was determined by X-ray diffraction (XRD). Passive film was formed on this alloy at a passivation potential of ?0.85 V vs SCE. Corrosion resistance of the passive film on the surface of the Al?2Li binary alloy was tested by electrochemical impedance spectroscopy (EIS). Structure of the passive film was analyzed by potentiostatic polarization and the Mott?Schottky (M?S) approach. Results show that the corrosion potentials of Al?2Li alloy initially move toward the positive, then toward negative, along with increasing aging time. EIS spectra of the passive films on the solution treatment and aging have two capacitive impedance arcs; the corrosion mechanism is not changed by the aging treatment. Corrosion resistance of the passive film is, in order from high to low, aged 20 h > solution treatment > aged 40 h > aged 1 h, and is related to the compactness and acceptor concentration of the passive film.
- Al?2Li binary alloy /
- aging /
- passive film /
- corrosion resistance /
- structure

HTML全文

圖 1 在3.5% NaCl水溶液中Al?2Li合金的動電位極化曲線

Figure 1. Potentiodynamic polarization plots of Al?2Li alloy with different aging time in 3.5% NaCl solution

下載: 全尺寸圖片幻燈片

圖 2 Al?2Li合金在?0.85 V vs SCE鈍化電位下的EIS結果. （a）Nyquist圖;（b）Bode圖

Figure 2. Electrochemical impedance spectra(EIS) of the Al?2Li alloy at ?0.85 V vs SCE: (a) Nyquist; (b) Bode

下載: 全尺寸圖片幻燈片

圖 3 Al?2Li合金電極的等效電路圖. （a）R_s（R_fQ_f）（R_ctC_dl）；（b）R_s（R_fQ_f）（R_ctQ_dl）

Figure 3. Equivalent circuit diagram of the Al?2Li Alloy electrode: (a) R_s(R_fQ_f)(R_ctC_dl); (b) R_s(R_fQ_f)(R_ctQ_dl)

下載: 全尺寸圖片幻燈片

圖 4 Al?2Li合金恒電位極化. （a）鈍化電流密度與時間的雙對數曲線; （b）擬合結果

Figure 4. Potentiostatic polarization plots of the Al?2Li alloy: (a) double-log plots of passive current density with time; (b) fitting slope values

下載: 全尺寸圖片幻燈片

圖 5 Al?2Li合金?0.85 V vs SCE電位下形成鈍化膜的M?S曲線

Figure 5. M?S plots of the passive films formed at ?0.85 V vs SCE of the Al?2Li alloy

下載: 全尺寸圖片幻燈片

圖 6 Al?2Li合金X射線衍射結果

Figure 6. X-ray diffraction (XRD) result of the Al?2Li alloy

下載: 全尺寸圖片幻燈片

圖 7 Al?2Li合金鈍化膜結構示意圖

Figure 7. Sketch map of the passive films formed on the Al?2Li alloy

下載: 全尺寸圖片幻燈片

表 1 Al?2Li合金動電位極化曲線的擬合結果

Table 1. Fitting results of potentiodynamic polarization plots of the Al?2Li alloy

時效時間/h	E_corr/V（vs SCE）	I_corr /（10^?7·A·cm^?2）	E_p/（V vs SCE）
0	?1.115	3.23	?0.755
1	?0.964	6.34	?0.746
20	?1.072	0.73	?0.750
40	?1.114	3.26	?0.753

下載: 導出CSV

表 2 Al?2Li合金鈍化膜EIS擬合結果（圖3（a））

Table 2. Fitting parameters of EIS for the Al?2Li alloy (Fig. 3(a))

時效時間/h	R_s/（Ω·cm²）	Q_f		R_f/（kΩ·cm²）	C_dl/（μF·cm^?2）	R_ct/（kΩ·cm²）
時效時間/h	R_s/（Ω·cm²）	Y₀/（Ω^?1·cm^?2·s^?n）	n	R_f/（kΩ·cm²）	C_dl/（μF·cm^?2）	R_ct/（kΩ·cm²）
0	2.46	2.41×10^?6	0.69	22.81	76.90	19.9
1	3.22	3.23×10^?4	0.65	19.19	89.92	16.7
20	3.92	2.33×10^?6	0.66	25.01	71.96	22.57

下載: 導出CSV

表 3 Al?2Li合金鈍化膜EIS擬合結果（圖3（b））

Table 3. Fitting parameters of EIS for the Al?2Li alloy (Fig. 3(b))

時效時間/h	R_s/（Ω·cm²）	Q_f		R_f/（kΩ·cm²）	Q_dl		R_ct/（kΩ·cm²）
時效時間/h	R_s/（Ω·cm²）	Y₀/（Ω^?1·cm^?2·s^?n）	n	R_f/（kΩ·cm²）	Y₀/（Ω^?1·cm^?2·s^?n）	n	R_ct/（kΩ·cm²）
40	2.08	2.46×10^?4	0.58	0.154	6.25×10^?5	0.86	33.43

下載: 導出CSV
