Effect of cold wire position on the welding process in twin-arc integrated cold wire hybrid welding
-
摘要: 搭建了雙電弧集成冷絲復合焊接系統，研究了冷絲不同位置對焊接過程的影響機理，其中包括冷絲作用位置對其加熱熔化作用及表面成形的影響。實驗結果表明：冷絲從兩引導焊絲正前方送入時，熔池前端對冷絲的加熱熔化作用不充分，冷絲末端會頂觸熔池底部，隨著冷絲的持續送進和母材的向后移動，某一時刻冷絲回彈，焊絲末端的熔滴彈出落在母材表面形成大顆粒飛濺。當冷絲從側面送入時，熔池一側的溫度較低，影響熔池金屬的流動，導致最終的焊縫成形不對稱分布。當冷絲從兩引導焊絲正后方送入熔池時，冷絲始終插入熔池中，焊接過程穩定，是理想的冷絲作用位置。此外，隨著冷絲送絲速度的增加，兩種脈沖電流模式（同相和反相）下，熔敷率均隨之增加，且相差不大。同相脈沖電流下電弧對冷絲的加熱熔化作用最強烈，反相脈沖電流下次之，直流模式下最弱。
-
關鍵詞:
- 雙電弧集成冷絲復合焊 /
- 冷絲作用位置 /
- 冷絲送絲速度 /
- 熔敷率 /
- 電流模式
Abstract: With rapid social and economic development, high-efficiency welding technology has become an important development direction in the field of welding. In recent years, scholars and professionals in many countries have devoted themselves to further increasing the welding efficiency by improving welding materials, welding process, and arc-welding equipment. The welding efficiency can be increased using two approaches: one is increasing the welding speed, the other is increasing the welding deposition rate. Considering these two methods, typical technologies such as multiwire submerged arc welding (SAW) and multiwire gas metal arc welding (GMAW) were proposed. A twin-arc integrated cold wire hybrid welding system was established. The mechanical effect of the cold wire position on the welding process was studied, including its effects on heating, melting, and weld surface formation. Results show that the melting of cold wire depends on the front end of the weld pool, and the melting effect of the weld pool on the cold wire is not sufficient when the cold wire is fed in front of two leading wires. The end of the cold wire makes contact with the bottom surface of the weld pool with the continuous feeding of the cold wire. Droplets melted at the wire ends are ejected and fall on the base metal surface to generate a globular spatter with the backward motion of the base metal. The thermal distribution on the side of the weld pool decreases as the cold wire is fed inside of the two leading wires. Hence, the flow of molten metal is affected, ultimately leading to an uneven weld formation. The cold wire is stably inserted into the weld pool when fed behind the two leading wires, representing the optimum cold wire position. Moreover, the deposition rates increase with an increase in the cold wire feed speed and show little change under two-pulse phase differences (in-phase and reverse-phase pulse differences). The effect of arc heating and melting on the cold wire was most intense at the in-phase pulse current, followed by the reverse-phase pulse current and subsequently direct current. -
圖 1 雙電弧集成冷絲復合焊焊接系統示意圖
Figure 1. Schematic of twin-arc integrated cold wire hybrid welding system
圖 2 冷絲不同作用位置的示意圖。（a）位于兩引導焊絲正后方；（b）位于兩引導焊絲正前方；（c）位于兩引導焊絲側面
Figure 2. Schematic of cold wire different locations: (a) right behind the two leading wires; (b) in front of the two leading wires; (c) in side of the two leading wires
圖 6 冷絲不同作用位置時的焊縫宏觀形貌。（a）冷絲在后；（b）冷絲在側面；（c）冷絲在前
Figure 6. Welding appearances at different cold wire positions: (a) cold wire in the rear; (b) cold wire in the side; (c) cold wire in the front
圖 7 冷絲送絲速度與熔敷速度的關系
Figure 7. Relationship between the cold wire feed speed and deposition rate
圖 8 三種電流模式下冷絲在熔池中的狀態與送絲速度間的對應關系。（a）同相脈沖電流；（b）反相脈沖電流；（c）直流
Figure 8. Corresponding relationships between the states of cold wire in the weld pool and feed wire speeds under three current modes: (a) in-phase pulse current; (b) reverse-phase pulse current; (c) direct current
中文字幕在线观看表 1 兩引導焊絲上的基本脈沖電參數
Table 1. Basic pulse parameters of the two leading wires
Preset current/A Preset voltage/V Pulse peak current/A Pulse peak voltage/V Pulse base current/A Pulse base voltage/V Pulse peak time/ms Pulse basic time/ms Frequency/Hz 140 24 600 40 100 20 3.2 8 89
下載: 導出CSV
-
參考文獻
[1] Chen L S. Discussion on the production status and development of welding technology. Nonferrous Met Abstr, 2015, 30(2): 46陳連生. 焊接生產現狀與焊接技術的發展研究. 有色金屬文摘, 2015, 30(2):46 [2] Tusek J. Raising arc welding productivity. Weld Rev Int, 1996, 15(3): 102 [3] ?berg A E, ?strand E. Improved productivity by reduced variation in gas metal arc welding (GMAW). Int J Adv Manuf Technol, 2017, 92(1-4): 1027 doi: 10.1007/s00170-017-0214-4 [4] Zhang J G, Wang H Y, Wang X, et al. Research status and prospect of high efficient welding technology for pipeline steel. Hot Work Technol, 2018, 47(3): 18張錦剛, 王海燕, 王茜, 等. 管線鋼高效焊接技術的研究現狀及前景分析. 熱加工工藝, 2018, 47(3):18 [5] Liu L M, Hu C H, Yu S B, et al. A triple-wire indirect arc welding method with high melting efficiency of base metal. J Manuf Process, 2019, 44: 252 doi: 10.1016/j.jmapro.2019.05.022 [6] Zhang K, Jiang H T, Meng Q, et al. Effect of the welding speed on the microstructure and the mechanical properties of robotic friction stir welded AA7B04 aluminum alloy. Chin J Eng, 2018, 40(12): 1525張坤, 江海濤, 孟強, 等. 焊接速度對機器人攪拌摩擦焊AA7B04鋁合金接頭組織和力學性能的影響. 工程科學學報, 2018, 40(12):1525 [7] Kah P, Suoranta R, Martikainen J. Advanced gas metal arc welding processes. Int J Adv Manuf Technol, 2013, 67: 655 doi: 10.1007/s00170-012-4513-5 [8] Zhao Y Y, Lee P S, Chung H. Effect of pulsing parameters on drop transfer dynamics and heat transfer behavior in pulsed gas metal arc welding. Int J Heat Mass Transf, 2019, 129: 1110 doi: 10.1016/j.ijheatmasstransfer.2018.10.037 [9] Xu Y L, Lv N, Fang G, et al. Welding seam tracking in robotic gas metal arc welding. J Mater Process Technol, 2017, 248: 18 doi: 10.1016/j.jmatprotec.2017.04.025 [10] Sproesser G, Chang Y J, Pittner A, et al. Energy efficiency and environmental impacts of high power gas metal arc welding. Int J Adv Manuf Technol, 2017, 91(9-12): 3503 doi: 10.1007/s00170-017-9996-7 [11] Mohammadijoo M, Collins L, Henein H, et al. Evaluation of cold wire addition effect on heat input and productivity of tandem submerged arc welding for low-carbon microalloyed steels. Int J Adv Manuf Technol, 2017, 92(1-4): 817 doi: 10.1007/s00170-017-0150-3 [12] Zhu Z M, Fu P P, Yang Z Y, et al. Experimental research on factors influencing the current commutation process of variable-polarity arc welding. Chin J Eng, 2019, 41(4): 505朱志明, 符平坡, 楊中宇, 等. 變極性電弧焊接的電流換向過程影響因素試驗研究. 工程科學學報, 2019, 41(4):505 [13] Arita H, Morimoto T, Nagaoka S, et al. Development of advanced 3-electrode MAG high-speed horizontal fillet welding process. Weld World, 2009, 53(5-6): 35 doi: 10.1007/BF03266713 [14] Yokota Y, Shimizu H, Nagaoka S, et al. Development and application of the 3-electrode MAG high-speed horizontal fillet welding process. Weld World, 2012, 56(1-2): 43 doi: 10.1007/BF03321144 [15] Xu C, Hua X M, Ye D J, et al. An improved simulation model for three-wire gas metal arc welding. Int J Adv Manuf Technol, 2017, 90(5-8): 1447 doi: 10.1007/s00170-016-9419-1 [16] Gu Y, Hua X M, Ye D J, et al. Numerical simulation of hump suppression in high-speed triple-wire GMAW. Int J Adv Manuf Technol, 2017, 89: 727 doi: 10.1007/s00170-016-9119-x [17] Ma X L, Xu C, Wang W C, et al. Impact of welding parameters on arc characteristics in triple-wire welding. J Shanghai Jiao Tong Univ, 2020, 54(7): 682馬曉麗, 徐琛, 王偉成, 等. 三絲焊接參數對電弧形態特征的影響. 上海交通大學學報, 2020, 54(7):682 [18] Fang D S, Liu L M. Analysis of process parameter effects during narrow-gap triple-wire gas indirect arc welding. Int J Adv Manuf Technol, 2017, 88(9-12): 2717 doi: 10.1007/s00170-016-8802-2 [19] Fang D S, Song G, Liu L M. A novel method of triple-wire gas indirect arc welding. Mater Manuf Process, 2016, 31(3): 352 doi: 10.1080/10426914.2015.1058949 [20] Liu L M, Fang D S, Song G. Experimental investigation of wire arrangements for narrow-gap triple-wire gas indirect arc welding. Mater Manuf Process, 2016, 31(16): 2136 doi: 10.1080/10426914.2015.1090603 [21] Wang F Z. Esab ice saw. Electr Weld Mach, 2016, 46(3): 11王富州. 伊薩ICETM集成冷絲埋弧焊. 電焊機, 2016, 46(3):11 [22] Raudsepp H. Integrated cold electrode—latest advancement in Submerged Arc Welding. Electr Weld Mach, 2015, 45(5): 23Hannes Raudsepp. 集成冷絲—埋弧焊新技術. 電焊機, 2015, 45(5):23 [23] Xiang T, Li H, Wei H L, et al. Effects of filling status of cold wire on the welding process stability in twin-arc integrated cold wire hybrid welding. Int J Adv Manuf Technol, 2016, 83(9-12): 1583 doi: 10.1007/s00170-015-7686-x [24] Wu K Y, Cao X W, Yin T, et al. Metal transfer process and properties of double-wire double pulsed gas metal arc welding. J Manuf Process, 2019, 44: 367 doi: 10.1016/j.jmapro.2019.06.019 [25] Xiang T, Li H, Huang C Q, et al. The metal transfer behavior and the effect of arcing mode on metal transfer process in twin-arc integrated cold wire hybrid welding. Int J Adv Manuf Technol, 2017, 90(1-4): 1043 doi: 10.1007/s00170-016-9451-1 [26] Xiang T, Li H, Wei H L, et al. Arc characteristics and metal transfer behavior of twin-arc integrated cold wire hybrid welding. Int J Adv Manuf Technol, 2016, 87(9-12): 2653 doi: 10.1007/s00170-016-8663-8 -
