Mechanism and performance of coal spontaneous combustion with a halide carrier inorganic salt inhibitor
-
摘要: 為了研究鹵鹽載體無機鹽阻化劑對煤自燃的阻化機理及性能，采用差示掃描量熱儀（DSC）測試了在稀土水滑石、MgCl2和鹵鹽載體無機鹽三種不同阻化劑作用下，煤自燃過程中分階段特征、特征溫度、熱效應和表觀活化能等參數變化規律。測試結果表明，稀土水滑石層板的?OH能夠與煤分子中的?COOH等酸性官能團產生弱氫鍵，造成?COOH等酸性官能團的活性減弱；Mg2+與煤分子中的—COO?發生絡合作用，生成了?COOMg?，造成?COO?內的 C=O活性減弱是鹵鹽載體無機鹽抑制煤自燃的主要機理。煤樣中添加鹵鹽載體無機鹽后DSC曲線吸熱峰均出現雙峰或多峰，且較原煤的峰值溫度后移了50～60 ℃、T1溫度后移了90～100 ℃、總放熱量降低了19～27 kJ?g?1，而且有效的提高了煤體各階段的表觀活化能。研究表明鹵鹽載體無機鹽阻化劑可有效抑制煤自燃反應進程。Abstract: Coal spontaneous combustion seriously restricts the safe production of coal mines, and adding an inhibitor is one of the effective methods to prevent coal spontaneous combustion. To improve the pertinence and high efficiency of the inhibitor, this paper considered the intrinsic properties and external conditions that affect the occurrence of coal spontaneous combustion, combined with the characteristics that the rare earth hydrotalcite can effectively improve the thermal stability, coupling, and flame retardancy of the coal and the halide inhibitor. The halide inhibitor can enhance the permeability, dispersion, and uniformity of the rare earth hydrotalcite as a carrier. The halide carrier inorganic salt inhibitor was prepared. To study the inhibition mechanism and performance of the halide carrier inorganic salt inhibitor on coal spontaneous combustion, differential scanning calorimetry (DSC) was used to test the variation law of parameters, such as stage characteristics, characteristic temperature, thermal effect, and apparent activation energy in the process of coal spontaneous combustion under the action of a rare earth hydrotalcite, MgCl2 and a halide carrier inorganic salt inhibitor. Test results reveal that the OH of the rare earth hydrotalcite laminate can generate a weak hydrogen bond with acidic functional groups such as ?COOH in coal molecules so that the activity of the acidic functional groups is weakened. Mg2+ complexes with ?COO? in coal molecules to form ?COOMg?, resulting in the weakening of the C=O activity in ?COO?, which is the main mechanism of the halide carrier inorganic salts inhibiting coal spontaneous combustion. The endothermic peak of the DSC curve appears as a double peak or multi-peak after the addition of halide carrier inorganic salts to the coal sample. Compared with the raw coal, the peak temperature is shifted back by 50–60 ℃, the T1 temperature is shifted back by 90–100 ℃, and the total heat release decreased by 19–27 kJ?g?1. Furthermore, the apparent activation energy of each stage of the coal body is effectively improved. Results revealed that the halide carrier inorganic salt inhibitor could effectively inhibit the reaction process of coal spontaneous combustion.
-
圖 1 試驗樣品掃描電鏡照片。（a）試驗樣品1；（b）試驗樣品2；（c）試驗樣品7；（d）試驗樣品8
Figure 1. Test sample SEM: (a) sample 1; (b) sample 2; (c) sample 7; (d) sample 8
圖 2 試驗樣品EDS圖。（a）試驗樣品1；（b）試驗樣品2；（c）試驗樣品7；（d）試驗樣品8
Figure 2. Test sample EDS: (a) sample 1; (b) sample 2; (c) sample 7; (d) sample 8
圖 3 試驗樣品熱釋放速率曲線圖。（a）試驗樣品1～6；（b）試驗樣品7～12
Figure 3. Curve of the heat release rate of the test sample: (a) sample 1–6; (b) sample 7–12
圖 4 各樣品熱釋放速率曲線圖。（a）試驗樣品1；（b）試驗樣品2；（c）試驗樣品3；（d）試驗樣品4；（e）試驗樣品5；（f）試驗樣品6；（g）試驗樣品7；（h）試驗樣品8；（i）試驗樣品9；（j）試驗樣品10；（k）試驗樣品11；（l）試驗樣品12
Figure 4. Heat release rate curve: (a) sample 1；(b) sample 2；(c) sample 3；(d) sample 4; (e) sample 5；(f) sample 6；(g) sample 7；(h) sample 8; (i) sample 9；(j) sample 10；(k) sample 11；(l) sample 12
圖 5 試驗樣品緩慢放熱階段表觀活化能曲線。（a）試驗樣品1；（b）試驗樣品7
Figure 5. Apparent activation energy curve of the test sample during the slow heat release stage: (a) sample 1; (b) sample 7
圖 6 試驗樣品快速放熱階段表觀活化能曲線。（a）試驗樣品1；（b）試驗樣品7
Figure 6. Apparent activation energy curve of the test sample during the rapid heat release stage: (a) sample 1; (b) sample 7
表 1 煤的工業分析與元素分析（質量分數）
Table 1. Industrial analysis and element analysis of coal
% Proximate analysis Ultimate analysis Mad Aad Vad FCad Cdaf Hdaf Nda Oda Sdaf 4.66 15.84 32.88 46.62 76.04 3.95 0.68 19.25 0.08
下載: 導出CSV
表 2 阻化劑配制成分表（質量分數）
Table 2. Composition list of the inhibitor
% Sample Rare earth
hydrotalciteH2O Sample MgCl2 Rare earth hydrotalcite H2O 1 0 100 7 20 0 80 2 1 99 8 20 1 79 3 3 97 9 20 3 77 4 5 95 10 20 5 75 5 7 93 11 20 7 73 6 9 91 12 20 9 71
下載: 導出CSV
表 3 試驗樣品在不同氧化階段的放熱量
Table 3. Heat release of test samples at different oxidation stages
Sample Total heat released/
(J?mg?1)Total heat absorbed
(heat absorption stage)/
(J?mg?1)Slow heat release stage Rapid heat release stage Heat released/
(J?mg?1)Percentage of total
heat released /%Heat released/
(J?mg?1)Percentage of total
heat released /%1 74.31 1.72 29.49 39.69 44.82 60.31 2 88.76 1.6 30.02 33.82 58.74 66.18 3 98.6 0.12 25.46 25.82 73.14 74.17 4 94.48 0.13 21.68 22.94 72.8 77.05 5 103.83 0.31 27.37 26.36 76.46 73.64 6 98.13 0.48 33.53 34.17 64.6 65.83 7 63.09 1.17 19.22 30.46 43.87 69.53 8 49.17 1.06 15.63 31.79 33.54 68.21 9 53.31 1.08 16.18 30.35 37.13 69.65 10 55.37 1.6 17.73 32.02 37.64 67.98 11 47.11 1.77 16.06 34.09 31.05 65.91 12 48.68 2.31 16.18 33.24 32.5 66.76
下載: 導出CSV
表 4 緩慢放熱階段表觀活化能參數
Table 4. Apparent activation energy parameters in the slow heat release stage
Sample Fitting linear
equationApparent activation
energy, E /
(J·mol–1)Correlation
coefficient,
R21 y=?3392.23468x+3.47896 28203.0391 0.97832 2 y=?4771.26045x+7.20905 39668.25938 0.95058 3 y=?3677.22585x+4.10123 30572.45572 0.96386 4 y=?3994.97463x+4.91556 33214.21907 0.97228 5 y=?4037.2746x+4.84162 33565.90102 0.9789 6 y=?4163.42638 x+5.24455 34614.72692 0.98845 7 y=?6428.62213x+9.04335 53447.56439 0.9187 8 y=?5443.14126x+7.62782 45254.27644 0.99003 9 y=?6140.78185x+9.03888 51054.4603 0.98428 10 y=?6653.1257x+ 9.91782 55314.08707 0.95261 11 y=?5802.11937x+8.25131 48238.82044 0.98814 12 y=?5623.12086 x+ 8.04004 46750.62683 0.9913
下載: 導出CSV
中文字幕在线观看表 5 快速放熱階段活化能參數
Table 5. Apparent activation energy parameters in the rapid heat release stage
Sample Fitting linear
equationApparent activation
energy, E /
(J·mol–1)Correlation
coefficient,
R21 y=?6881.26298x+7.89178 57210.82042 0.90249 2 y=?9425.37165x+11.82431 78362.5399 0.98207 3 y=?8808.86618x+10.8194 73236.91342 0.96555 4 y=?7816.14674x+9.33284 64983.444 0.9513 5 y=?7140.95942x+8.32359 59369.93645 0.93582 6 y=?7994.84827x+9.5651 66469.16852 0.94128 7 y=?9377.78707x+11.73499 77966.9217 0.97704 8 y=?10237.40606x+12.94076 85113.79398 0.95442 9 y=?8923.61423x+10.90617 74190.92871 0.94638 10 y=?10153.61359x+12.85178 84417.14339 0.9656 11 y=?10102.1723x+12.81694 83989.4605 0.9858 12 y=?10299.87431x+13.13003 85633.15501 0.96873
下載: 導出CSV
-
參考文獻
[1] Zhang Y N, Chen L, Zhao J Y, et al. Evaluation of the spontaneous combustion characteristics of coal of different metamorphic degrees based on a temperature-programmed oil bath experimental system. J Loss Prev Process Ind, 2019, 60: 17 doi: 10.1016/j.jlp.2019.03.007 [2] Zhang Y N, Hou Y C, Zhao J Y, et al. Heat release characteristic of key functional groups during low-temperature oxidation of coal. Combust Sci Technol, 2020: 1 [3] Zhao J Y, Deng J, Chen L, et al. Correlation analysis of the functional groups and exothermic characteristics of bituminous coal molecules during high-temperature oxidation. Energy, 2019, 181: 136 doi: 10.1016/j.energy.2019.05.158 [4] Guo W J. Experimental test and examination of the influential factors of the coal spontaneous combustion. J Saf Environ, 2018, 18(4): 1307郭文杰. 煤自燃特性影響因素的試驗研究. 安全與環境學報, 2018, 18(4):1307 [5] Zhu H T, Li Y N, Zhai Q Y, et al. Preparation and performance research of hydrotalcites containing rare earth element. Henan Chem Ind, 2019, 36(7): 15朱洪濤, 李巖娜, 翟秋月, 等. 稀土元素類水滑石的制備及其性能研究. 河南化工, 2019, 36(7):15 [6] Liu Y Z, Duan T X, Deng Q, et al. Preparation of calcined hydrotalcite and adsorption of Cr(VI). Guangzhou Chem Ind, 2020, 48(15): 109 doi: 10.3969/j.issn.1001-9677.2020.15.035劉奕禎, 段天欣, 鄧仟, 等. 焙燒水滑石的制備及其吸附Cr(VI)的研究. 廣州化工, 2020, 48(15):109 doi: 10.3969/j.issn.1001-9677.2020.15.035 [7] Pang Y Q, Zhang Q. Research of inhibitor suppression on coal spontaneous combustion by magnesium chloride. Datong Coal Sci Technol, 2020(3): 51龐葉青, 張奇. 阻化劑氯化鎂抑制煤自燃的實驗研究. 同煤科技, 2020(3):51 [8] Xu H Y. Experimental study of thermogravimetric kinetics on the composite inhibitor for inhibiting coal spontaneous combustion. Min Res Dev, 2019, 39(6): 79許紅英. 復合阻化劑抑制煤自燃的熱重動力學實驗研究. 礦業研究與開發, 2019, 39(6):79 [9] Ma D J, Tang Y B. Influence of associated metal elements in coal on low-temperature oxidation characteristics of coal. Coal Sci Technol, 2019, 47(2): 203馬冬娟, 唐一博. 煤中伴生金屬元素對煤低溫氧化特性的影響. 煤炭科學技術, 2019, 47(2):203 [10] Wang F S, Wang J T, Dong X W, et al. Experimental research on resistance characteristics of hypophosphite to coal spontaneous combustion. Saf Coal Mines, 2020, 51(5): 45王福生, 王建濤, 董憲偉, 等. 次磷酸鹽對煤自燃的阻化特性實驗研究. 煤礦安全, 2020, 51(5):45 [11] Jin Y F, Li Y H, Liu B. Research on inhibiting effects of LDHs on coal spontaneous combustion. Coal Technol, 2017, 36(10): 101金永飛, 李毅恒, 劉博. 稀土類水滑石的煤自燃阻化效果研究. 煤炭技術, 2017, 36(10):101 [12] Yang J X, Bai Z J. Experimental study on inhibition characteristic of LDHs inhibitor to bituminous coal. Saf Coal Mines, 2018, 49(8): 35楊計先, 白祖錦. LDHs阻化劑對煙煤的阻化特性實驗研究. 煤礦安全, 2018, 49(8):35 [13] Zhou X, Yuan H K, He P, et al. Effect of surface modifier on properties of Zn?Mg?Al hydrotalcites as heat stabilizer. Fine Chem, 2018, 35(8): 1389周喜, 袁浩坤, 何鵬, 等. 表面改性劑對Zn?Mg?Al水滑石熱穩定劑性能影響. 精細化工, 2018, 35(8):1389 [14] Wu W R, Liu T, Liu Z H, et al. Research progress of coal self ignition inhibitor. Appl Chem Ind, 2017, 46(2): 356武衛榮, 劉濤, 劉振輝, 等. 煤自燃阻化劑的研究進展. 應用化工, 2017, 46(2):356 [15] Zhang Y T, Shi X Q, Li Y Q, et al. Inhibiting effects of Zn/Mg/Al layer double hydroxide on coal spontaneous combustion. J China Coal Soc, 2017, 42(11): 2892張玉濤, 史學強, 李亞清, 等. 鋅鎂鋁層狀雙氫氧化物對煤自燃的阻化特性. 煤炭學報, 2017, 42(11):2892 [16] Li J H, Wang B, Zhang A S, et al. Research on inhibition effect of halogen inhibitor on coal seam of Guotun Coal Mine. Coal Chem Ind, 2020, 43(5): 142李進海, 王兵, 張安山, 等. 鹵鹽阻化劑對郭屯煤礦煤層的阻化效果研究. 煤炭與化工, 2020, 43(5):142 [17] Dong X W, Ai Q X, Wang F S, et al. Research on thermal characteristics in the process of coal oxidation inhibition. J Saf Sci Technol, 2016, 12(4): 70董憲偉, 艾晴雪, 王福生, 等. 煤氧化阻化過程中的熱特性研究. 中國安全生產科學技術, 2016, 12(4):70 [18] Zhou K Q, Gao R, Qian X D. Self-assembly of exfoliated molybdenum disulfide (MoS2) nanosheets and layered double hydroxide (LDH): towards reducing fire hazards of epoxy. J Hazard Mater, 2017, 338: 343 doi: 10.1016/j.jhazmat.2017.05.046 [19] Wu B, Lou P, Wang C. Analysis of coal spontaneous combustion control by inhibitor. China Coal, 2014, 40(6): 117 doi: 10.3969/j.issn.1006-530X.2014.06.031吳兵, 婁鵬, 王超. 阻化劑防治煤自燃效果分析. 中國煤炭, 2014, 40(6):117 doi: 10.3969/j.issn.1006-530X.2014.06.031 [20] Zheng L F. Test and analysis on salty retardants performance to restrain coal oxidized spontaneous combustion. Coal Sci Technol, 2010, 38(5): 70鄭蘭芳. 抑制煤氧化自燃的鹽類阻化劑性能分析. 煤炭科學技術, 2010, 38(5):70 [21] Li X P, Chen Y G, Zhang J S, et al. Study on the inhibition effect of chlorine salt composite inhibitor on spontaneous combustion of different coal samples. Coal Eng, 2020, 52(2): 106李緒萍, 陳映光, 張金山, 等. 氯鹽復合阻化劑對不同煤樣自燃阻化效果的研究. 煤炭工程, 2020, 52(2):106 [22] Yang Y. Mechanism and Performance of Inhibitor Based on Oxidation Characteristic of the Spontaneous Combustion of Coal [Dissertation]. Xi’an: Xi’an University of Science and Technology, 2015楊漪. 基于氧化特性的煤自燃阻化劑機理及性能研究[學位論文]. 西安: 西安科技大學, 2015 [23] Zhang X H, Ding F, Zhang Y T, et al. Experimental study on LDHs composite inhibitor to coal resistance property. Coal Sci Technol, 2017, 45(1): 84張辛亥, 丁峰, 張玉濤, 等. LDHs復合阻化劑對煤阻化性能的試驗研究. 煤炭科學技術, 2017, 45(1):84 [24] Duan Z Y, Wang F. Influence of MgCl2 on initial oxidation and secondary oxidation of coal. Saf Coal Mines, 2017, 48(6): 13段志勇, 王飛. MgCl2對煤一次氧化與二次氧化影響的實驗研究. 煤礦安全, 2017, 48(6):13 [25] Zhao J Y, Zhang Y L, Deng J, et al. Key functional groups affecting the release of gaseous products during spontaneous combustion of coal. Chin J Eng, 2020, 42(9): 1139趙婧昱, 張永利, 鄧軍, 等. 影響煤自燃氣體產物釋放的主要活性官能團. 工程科學學報, 2020, 42(9):1139 -
