Flow field characteristics of a coherent jet using various lance tip structures

WEI Guang-sheng; ZHU Rong; CHENG Shu-jiang; LIU Fu-hai; DONG Kai; YAO Liu-jie

doi:10.13374/j.issn2095-9389.2020.03.20.s17

Volume 42 Issue S

Dec. 2020

Turn off MathJax

Article Contents

Article Navigation > Chinese Journal of Engineering > 2020 > 42(S): 76-82

WEI Guang-sheng, ZHU Rong, CHENG Shu-jiang, LIU Fu-hai, DONG Kai, YAO Liu-jie. Flow field characteristics of a coherent jet using various lance tip structures[J]. Chinese Journal of Engineering, 2020, 42(S): 76-82. doi: 10.13374/j.issn2095-9389.2020.03.20.s17

Citation:

WEI Guang-sheng, ZHU Rong, CHENG Shu-jiang, LIU Fu-hai, DONG Kai, YAO Liu-jie. Flow field characteristics of a coherent jet using various lance tip structures[J]. Chinese Journal of Engineering, 2020, 42(S): 76-82. doi: 10.13374/j.issn2095-9389.2020.03.20.s17

Citation:

PDF( 1062 KB)

Flow field characteristics of a coherent jet using various lance tip structures

doi: 10.13374/j.issn2095-9389.2020.03.20.s17

1.
School of Metallurgical and Ecological Engineering, University of Science and Technology Beijing, Beijing 100083, China
2.
Key Laboratory of Fluid Interaction with Material (Ministry of Education), University of Science and Technology Beijing, Beijing 100083, China
3.
Yanzhou Gaolida Co. Ltd., Yanzhou 225800, China
4.
National Center for Materials Service Safety, University of Science and Technology Beijing, Beijing 100083, China

More Information

Corresponding author: E-mail: liufuhaisteel@126.com
Received Date: 2020-03-20
Publish Date: 2020-12-25

Abstract

Abstract

Coherent lances have been playing an extremely important role in the process of supplying oxygen to an electrical arc furnace, which has been widely used in metallurgy, and its metallurgical and operational benefits have been well reported. When compared with the conventional supersonic oxygen lance, the coherent lance could increase the oxygen utilization rate, strengthen penetration ability, and achieve a good stirring effect. However, there was limited research about the flow field characteristics of a coherent jet using different restriction structures for a coherent lance tip. This paper analyzed velocity and temperature profiles at various parameters and conditions. Both numerical simulation and combustion experiment have been carried out to investigate the velocity and temperature profiles using three kinds of restriction structures at room and high ambient temperature conditions. Further, the impact diameter and depth of the molten bath have also been analyzed at a certain lance height. The result shows that the restriction structure could delay energy transmission in a radial direction, which enlarges a high-temperature zone in an axial direction, resulting in the increase of the velocity potential core length and the improvement of the mixing ability of the main oxygen jet.
- coherent lance,
- flow field,
- numerical simulation,
- combustion experiment

FullText(HTML)

References(12)

References

[1]	Zhou X B, Ersson M, Zhong L C, et al. Mathematical and physical simulation of a top blown converter. Steel Res Int, 2014, 85(2): 273 doi: 10.1002/srin.201300310
[2]	Li Q, Li M M, Kuang S B, et al. Numerical simulation of the interaction between supersonic oxygen jets and molten slag-metal bath in steelmaking BOF process. Metall Mater Trans B, 2015, 46(3): 1494 doi: 10.1007/s11663-015-0292-3
[3]	Asahara N, Naito K I, Kitagawa I, et al. Fundamental study on interaction between top blown jet and liquid bath. Steel Res Int, 2011, 82(5): 587 doi: 10.1002/srin.201100041
[4]	王慧, 朱榮, 呂明, 等. 提釩用旋流氧槍噴頭的數值模擬. 北京科技大學學報, 2014, 36(1):89 Wang H, Zhu R, Lü M, et al. Numerical simulation of swirl-type lances in vanadium extraction process. J Univ Sci Technol Beijing, 2014, 36(1): 89
[5]	Alam M, Naser J, Brooks G, et al. Computational fluid dynamics modeling of supersonic coherent jets for electric arc furnace steelmaking process. Metall Mater Trans B, 2010, 41(6): 1354 doi: 10.1007/s11663-010-9436-7
[6]	Sumi I, Kishimoto Y, Kikuchi Y, et al. Effect of high-temperature field on supersonic oxygen jet behavior. ISIJ Int, 2006, 46(9): 1312 doi: 10.2355/isijinternational.46.1312
[7]	Tang G W, Chen Y C, Silaen A K, et al. Effects of fuel input on coherent jet length at various ambient temperatures. Appl Therm Eng, 2019, 153: 513 doi: 10.1016/j.applthermaleng.2019.03.019
[8]	Liu F H, Sun D B, Zhu R, et al. Effect of shrouding gas temperature on characteristics of a supersonic jet flow field with a shrouding laval nozzle structure. Metall Mater Trans B, 2018, 49(4): 2050 doi: 10.1007/s11663-018-1272-1
[9]	Odenthal H J, Bui P, Reifferscheid M, et al. Advanced design of burner/injector systems in electric arc furnaces (EAF)//4th Intern. Conf. on Modelling and Simulation of Metallurgical Processes in Steelmaking. Dusseldorf, 2011: 1
[10]	Wei G S, Zhu R, Wu X T, et al. Study on the fluid flow characteristics of coherent jets with CO₂ and O₂ mixed injection in electric arc furnace steelmaking processes. Metall Mater Trans B, 2015, 46(3): 1405 doi: 10.1007/s11661-014-2715-1
[11]	Papamoschou D, Roshko A. The compressible turbulent shear layer: an experimental study. J Fluid Mech, 1988, 197: 453 doi: 10.1017/S0022112088003325
[12]	Launder B E, Spalding D B. The numerical computation of turbulent flows. Comput Meth Appl Mech Eng, 1974, 3(2): 269 doi: 10.1016/0045-7825(74)90029-2
