Loop Tearing LooP Analysis
-
摘要: 本文提出了一種與文獻[J]中給出的NTNA法相對偶的新的撕裂方法——回路撕裂回路分析法（Loop Tearing Loop Analysis,簡稱LTIA）;給出了LTLA的電網絡拓撲及電耦合條件和撕裂方程的嚴格推導,進而給出了LTLA的電路理論解釋及一個便于理解和實現的算法;以供參考。文章通過一個示例說明了LTLA的撕裂步驟,與其它的撕裂法進行比較,指出了LTLA適用的情況。Abstract: A new tearing approach which is dual to Node-Tearing Nodal Analys is,Called Loop Tearing Loop Analysis (LTLA for Short),is presented in this paper,The topological and electrical coupling conditions of LTLA are discussed.A Circuit theoretic interpretation of LTLA is also given. A convenient algorithm is presented to explain each step of the LTL A. His pointed out the most suitable situation in which LTLA is to be used.
-
