WC-Co硬質合金刀片熱絲法金剛石薄膜涂層附著力

王四根, 唐偉忠, 呂反修, 佟玉梅, 聶瑋

文章導航 > 工程科學學報 > 1998 > 20(2): 143-146

王四根, 唐偉忠, 呂反修, 佟玉梅, 聶瑋. WC-Co硬質合金刀片熱絲法金剛石薄膜涂層附著力[J]. 工程科學學報, 1998, 20(2): 143-146. doi: 10.13374/j.issn1001-053x.1998.02.033

引用本文:

王四根, 唐偉忠, 呂反修, 佟玉梅, 聶瑋. WC-Co硬質合金刀片熱絲法金剛石薄膜涂層附著力[J]. 工程科學學報, 1998, 20(2): 143-146. doi: 10.13374/j.issn1001-053x.1998.02.033

Wang Sigen, Tang Weizhong, Lu Fanxiu, Tong Yumei, Nie Wei. Adhesion of Diamond Coating on WC-6% Co for Cutting Tools by Hot Filament CVD[J]. Chinese Journal of Engineering, 1998, 20(2): 143-146. doi: 10.13374/j.issn1001-053x.1998.02.033

Citation:

Wang Sigen, Tang Weizhong, Lu Fanxiu, Tong Yumei, Nie Wei. Adhesion of Diamond Coating on WC-6% Co for Cutting Tools by Hot Filament CVD[J]. Chinese Journal of Engineering, 1998, 20(2): 143-146. doi: 10.13374/j.issn1001-053x.1998.02.033

王四根, 唐偉忠, 呂反修, 佟玉梅, 聶瑋. WC-Co硬質合金刀片熱絲法金剛石薄膜涂層附著力[J]. 工程科學學報, 1998, 20(2): 143-146. doi: 10.13374/j.issn1001-053x.1998.02.033

引用本文:

王四根, 唐偉忠, 呂反修, 佟玉梅, 聶瑋. WC-Co硬質合金刀片熱絲法金剛石薄膜涂層附著力[J]. 工程科學學報, 1998, 20(2): 143-146. doi: 10.13374/j.issn1001-053x.1998.02.033

Wang Sigen, Tang Weizhong, Lu Fanxiu, Tong Yumei, Nie Wei. Adhesion of Diamond Coating on WC-6% Co for Cutting Tools by Hot Filament CVD[J]. Chinese Journal of Engineering, 1998, 20(2): 143-146. doi: 10.13374/j.issn1001-053x.1998.02.033

Citation:

Wang Sigen, Tang Weizhong, Lu Fanxiu, Tong Yumei, Nie Wei. Adhesion of Diamond Coating on WC-6% Co for Cutting Tools by Hot Filament CVD[J]. Chinese Journal of Engineering, 1998, 20(2): 143-146. doi: 10.13374/j.issn1001-053x.1998.02.033

WC-Co硬質合金刀片熱絲法金剛石薄膜涂層附著力

doi: 10.13374/j.issn1001-053x.1998.02.033

北京科技大學材料科學與工程學院, 北京 100083

基金項目:

國家“863”高科技資助項目

作者簡介:
王四根,男,31歲,講師,博士

中圖分類號: TQ164
計量
- 文章訪問數: 256
- HTML全文瀏覽量: 81
- PDF下載量: 7
- 被引次數: 0
出版歷程
- 收稿日期: 1997-08-12
- 網絡出版日期: 2021-08-27

Adhesion of Diamond Coating on WC-6% Co for Cutting Tools by Hot Filament CVD

Material Science and Engineering, UST Beijing, Beijing 100083, China

摘要: 用熱絲法研究了WC-6%Co硬質合金刀片金剛石薄膜涂層附著力。結果表明:采用溫度為80℃,(HCl:HNO₃:H₂O)(體積比)為1:1:1溶液對硬質合金刀片表面去Co 15min后,經40μm金剛石粉及1.5μm金剛石加20μmTaC混合粉進行超聲預處理,結果表明,沉積的金剛石薄膜與硬質合金刀片基底具有良好的附著力,而經40μm金剛石粉處理的薄膜涂層組織與附著力要好一些。
- CVD /
- 金剛石薄膜 /
- 硬質合金 /
- 附著力
Abstract: CVD diamond coating on WC-6%Co for cutting tools has been investigated. The substrates were etched by HCl:HNO₃:H₃O(volume fraction) 1:1:1 solution at 80℃ for 15min to remove the cobalt from the surface. In order to enhance diamond nucleation, ultrasonic scratching pretreatment was applied by using diamond powder with 40μm parti-cle and the mixture of diamond powder with 1.5μm particle and TaC powder with 20 μm particle. The diamond deposition was performed by the hot filament CVD method.Adhesion was checked using Rockwell hardness machine with a loading capacity of 1 500 N, the experimental results show that the adhesion of CVD diamond coating to WC-6%Co substrate by ultrasonic scratched with diamond powder of 40 μ m particle is better than that of the mixture of diamond powder with 1.5μm particle and TaC powder with 20μm particle.
- CVD /
- diamond film /
- cemented carbide /
- adhesion
