Research for Plotting Diagram of Open-loop Systems
-
摘要: 從兩個方面對如何更好地繪制開環系統曲線進行了研究:(1)對它的計算方式進行有效的改進,推出實、虛頻特性計算通式,它方便于手算,更方便于計算機編程運算;(2)針對快速確定曲線有關形狀給出了2個判據,即起始漸近線判據和實、虛頻交點判據.Abstract: The method of effective plotting diagram of open-loop systems was studied in two aspects. Firstly, his calculus was efficaciously improved:the common formula of real and imaginary frequency response was advanced that is convenient for manual computation and more convenient for compute programming.Secondly, two criterions are posed for use of quick confirming the forms of diagram:they are the criterion of original asymptote and cross-point on real and imaginary axes.
-
