高爐密閉環境下雷達料面測量電磁特性仿真

doi: 10.13374/j.issn1001-053x.2011.01.012

陳先中^1,2, ,,
尹怡欣^1,2,
侯慶文^1,2,
魯億方^1,2,
王培元^1,2,
李敏^1,2

1. 北京科技大學信息工程學院, 北京 100083;
2. 北京科技大學鋼鐵流程先進控制教育部重點實驗室, 北京 100083

基金項目:

北京市教委重點學科資助項目

國家高技術研究發展計劃目標導向課題(No.2009AA04Z156)

東南大學毫米波國家重點實驗室資助項目(No.K200801)

詳細信息

通訊作者:
陳先中,E-mail:cxz@ustb.edu.cn

中圖分類號: TF068.27
計量
- 文章訪問數: 191
- HTML全文瀏覽量: 41
- PDF下載量: 7
- 被引次數: 0
出版歷程
- 收稿日期: 2010-01-31

Electromagnetic characteristic simulation of burden surface radar measurements in the BF closed environment

CHEN Xian-zhong^{1,2
, ,},
YIN Yi-xin^1,2,
HOU Qing-wen^1,2,
LU Yi-fang^1,2,
WANG Pei-yuan^1,2,
LI Min^1,2

1. School of Information Engineering, University of Science and Technology Beijing, Beijing 100083, China;
2. Key Laboratory of the Ministry of Education of China for Advanced Control for Iron and Steel Process, University of Science and Technology Beijing, Beijing 100083, China

摘要

摘要: 研究了高爐密閉環境下,雷達測量料面和料層厚度的微波電磁特性.利用電磁計算學和CST仿真方法,研究了媒介層介電常數模型,高爐料面和料層模型的微波透射、反射和吸收特性,高爐布料層數、雷達波入射角度和雷達波頻段與爐料媒介層介電常數重構關系模型.利用雷達波反射和透射電磁特性,結合高爐雷達的分布式雷達傳感陣列,并利用焦礦媒介層存在介電常數差的特征,實現了高爐內料面形狀和三層焦礦厚度在線3D重構.
- 高爐 /
- 分布式雷達傳感陣列 /
- 電磁特性 /
- 介電常數 /
- 仿真
Abstract: Microwave electromagnetic characteristics in radar measurements of burden surfaces and media thickness of an ore and coke (O/C) layer were researched in the closed environment of a blast furnace (BF). With electromagnetic calculations and CST simulation software, a dielectric constant model of the media layer was developed to study the transmission, reflection and absorption characteristics of the burden surface and the O/C layer in BF. Also a reconstruction relational model of the number of distributing O/C layers in BF, microwave angle and frequency band concerned with the dielectric constant of the media layer was established. Using trans-mission and reflection electromagnetic characteristics of radar waves, combining with BF radar distributed radar sensor array installation and the different dielectric constants of the O/C layer in BF, the three-dimensional reconstruction imaging of burden surfaces and O/C layer thickness in BF was realized on-line.
- blast furnaces /
- distributed radar sensor array /
- electromagnetic characteristics /
- dielectric constant /
- simulation
