高溫應變柵絲蠕變對應變測量精度影響與補償

王文瑞; 王剛; 胡挺; 張佳明

doi:10.13374/j.issn2095-9389.2017.01.012

高溫應變柵絲蠕變對應變測量精度影響與補償

doi: 10.13374/j.issn2095-9389.2017.01.012

王文瑞^1,2, ,,
王剛¹,
胡挺³,
張佳明¹

1) 北京科技大學機械工程學院, 北京 100083
2) 北京科技大學新型飛行器技術研究中心, 北京 100083
3) 北京福田康明斯發動機有限公司, 北京 102206

基金項目:

國家重大科學儀器設備開發專項資助項目（2011YQ14014507）；航空科學重點實驗室基金資助項目（20145674004）；中央高校基本科研業務費資助項目（FRF-TP-15-023A3）

詳細信息

中圖分類號: TH73
計量
- 文章訪問數: 710
- HTML全文瀏覽量: 291
- PDF下載量: 11
- 被引次數: 0
出版歷程
- 收稿日期: 2016-03-15

Influence of high temperature strain grid wire creep on strain measurement precision and its compensation

1) School of Mechanical Engineering, University of Science and Technology Beijing, Beijing 100083, China
2) Research Center for Aerospace Vehicles Technology, University of Science and Technology Beijing, Beijing 100083, China
3) Beijing Foton Cummins Engine Co. Ltd, Beijing 102206, China

摘要

摘要: 接觸式應變測量是材料和構件高溫力學行為研究的必要手段，其測量精度是高溫應變測量領域關注的熱點，而應變柵絲的高溫蠕變性能是測量精度的主要影響因素.本文首先根據材料蠕變機理分析應變片的蠕變特性，搭建高溫應變柵絲蠕變電測的系統，基于諾頓蠕變規律與試驗的測量結果，建立應變柵絲的高溫蠕變模型.論文基于應變柵絲蠕變輸出有限元模型，對柵絲蠕變輸出的影響因素進行研究；最后建立了高溫應變蠕變補償模型，以提高高溫應變測量精度，并取得了試驗驗證.
- 高溫 /
- 蠕變 /
- 應變片 /
- 應變測量 /
- 精度
Abstract: Contact strain measurement is a tool for studying the high temperature mechanical behavior of components and materials. The measurement precision is the key point of the high temperature strain measurement field, where creep is the main factor that affects the measurement precision at high temperature. In this paper, the creep characteristics of strain gauges were analyzed according to the material mechanism of creep by a high temperature strain measurement system. A grating creep model was obtained from the creep rule and experiment measurement results. Based on the grating creep model, the influence factors of strain gauge creep output were studied by the finite element model. Finally, a compensation model of high temperature strain creep was established to improve this high temperature strain measurement precision, and it was validated by experimental data.
- high temperature /
- creep /
- strain gauges /
- strain measurement /
- precision

HTML全文

參考文獻(5)

[1]	Wang W R, Zhang J M, Ren X, et al. Research and calibration experiment of characteristic parameters of high temperature resistance strain gauges. Sens Transducers, 2013, 159(11):324
[7]	Li J H, Han L, Duan J A, et al. Interface mechanism of ultrasonic flip chip bonding. Appl Phys Lett, 2007, 90(24):242902
[8]	Li J H, Wang D, Ji D A, et al. Structural design and control of a small-MRF damper under 50 N soft-landing applications. IEEE Trans Ind Inf, 2015, 11(3):612
[9]	Rohrbach C, Lexow J. Miniature force transducers with strain gauges. Measurement, 1986, 4(3):93
[10]	Mittmann H U, Czaika N, Czichos H. A new device for simultaneous measurement of friction force, normal force and friction coefficient. Wear, 1975, 31(1):179
