高溫時H13鋼中初生碳氮化物的分解研究

孫曉林; 王飛; 陳希春; 毛明濤; 郭漢杰

doi:10.13374/j.issn2095-9389.2017.05.010

高溫時H13鋼中初生碳氮化物的分解研究

doi: 10.13374/j.issn2095-9389.2017.05.010

孫曉林^1,2,
王飛²,
陳希春²,
毛明濤^1,2,
郭漢杰^1,3, ,

1) 北京科技大學冶金與生態工程學院, 北京 100083
2) 鋼鐵研究總院高溫材料研究所, 北京 100081
3) 高端金屬材料特種熔煉與制備北京市重點實驗室, 北京 100083

基金項目:

國家自然科學基金資助項目（51541402，51274031）

詳細信息

中圖分類號: TG142.1
計量
- 文章訪問數: 670
- HTML全文瀏覽量: 236
- PDF下載量: 15
- 被引次數: 0
出版歷程
- 收稿日期: 2016-05-19

Study on decomposition of primary carbonitrides in H13 steel under high temperature

1) School of Metallurgical and Ecological Engineering, University of Science and Technology Beijing, Beijing 100083, China
2) High Temperature Material Research Institute, Central Iron and Steel Research Institute, Beijing 100081, China
3) Beijing Key Laboratory of Special Melting and Preparation of High-end Metal Materials, Beijing 100083, China

摘要

摘要: 利用光學顯微鏡、掃描電鏡和電子探針研究了H13鋼中初生碳氮化物高溫分解時的形貌、尺寸、成分變化規律.原始初生碳氮化物主要為10~30 μm的長條狀（V_x，Mo_1-x）（C_y，N_1-y）及少量方形的（Ti_x，V_1-x）（C_y，N_1-y）.在1200℃保溫2.5 h后碳氮化物邊緣變為凹凸不平的鋸齒狀，然后形成細小的分解顆粒，10 h后碳氮化物平均長度減小為12.9 μm，主要為（Ti_x，V_1-x）（C_y，N_1-y）.當經過1250℃×5 h保溫后87%的碳氮化物發生分解，（V_x，Mo_1-x）（C_y，N_1-y）溶解消失，碳氮化物長度在20 μm以下，當保溫時間延長到10 h后碳氮化物長度均在10 μm以下，70%為方形并且93%分解形成細小顆粒，未分解的碳氮化物為（Ti_x，V_1-x）（C_y，N_1-y）.電子探針分析（Ti_x，V_1-x）（C_y，N_1-y）的分解與Fe元素擴散有關，高溫時Fe在（Ti_x，V_1-x）（C_y，N_1-y）中含量逐漸增加而Ti、V減少，優先在邊部曲率半徑較小部位或缺陷處分解，形成0.1~1 μm的細小分解顆粒，并由外向內以區域溶解方式使原始碳氮化物逐漸消失.雙亞點陣模型分析兩種碳氮化物的平衡溶解溫度和組成有關，試樣中大部分（Ti_x，V_1-x）（C_y，N_1-y）平衡溶解溫度在1200~1246℃之間，與實驗吻合較好.
- H13模具鋼 /
- 初生碳氮化物 /
- 高溫分解 /
- 成分變化 /
- 碳氮化物形貌和尺寸
Abstract: Optical microscopy (OM), scanning electron microscopy (SEM), and electron microprobe analysis (EMPA) were used to determine the nature of carbonitrides decomposition in H13 hot work die steel under high temperature, including its morphology, size and composition. Most of the original carbonitrides are long strip (V_x,Mo_1-x)(C_y,N_1-y) ranging between 10~30 μm with a few square (Ti_x,V_1-x)(C_y,N_1-y). The result shows that the edge of the carbonitrides becomes saw-toothed after holding at 1200℃ for 2.5 h, and fine decomposed particles are formed. The average length of carbonitrides, mainly (Ti_x,V_1-x)(C_y,N_1-y), is reduced to 12.9 μm as increasing the holding time for 10 h. When the steel is held at 1250℃ for 5 h, about 87% of the carbonitrides disintegrate, especially (V_x,Mo_1-x)(C_y,N_1-y) dissolving and disappearing, and the carbonitrides size is less than 20 μm. When holding at 1250℃ for 10 h, all the carbonitrides remained are (Ti_x,V_1-x)(C_y,N_1-y), of which 70% are square and 93% decompose to fine particles, and can be controlled to size below 10 μm. It is deduced that (Ti_x,V_1-x)(C_y,N_1-y) decomposition is related to Fe diffusion by EMPA analysis and that the Fe content in (Ti_x,V_1-x)(C_y,N_1-y) gradually enhances while Ti and V contents decline. The carbonitrides reliably decompose at the position of small curvature radius and defect position, forming fine particles of 0.1~1 μm. The original carbonitrides disappear by zone dissolution from outer to inner. The equilibrium temperature of carbonitrides dissolution has a relationship with its constituents based on the two-sublattice model, and dissolution temperature for most (Ti_x,V_1-x)(C_y,N_1-y) in sample is between 1200℃ and 1246℃, which fits well with the experimental results.
- H13 die steel /
- primary carbonitrides /
- high temperature decomposition /
- composition change /
- morphology and size of carbonitrides

HTML全文

參考文獻(12)

[3]	Maity S K, Ballal N B, Kawalla R. Development of ultrahigh strength steel by electroslag refining:effect of inoculation of titanium on the microstructures and mechanical properties. ISIJ Int, 2006, 46(9):1361
[7]	Zhou J, Ma D S, Chi H X, et al. Microstructure and properties of hot working die steel H13 MOD. J Iron Steel Res Int, 2013, 20(9):117
[9]	Lan J, He J J, Ding W J, et al. Effect of rare earth metals on the microstructure and impact toughness of a cast 0.4C-5Cr-1.2Mo-1.0V steel. ISIJ Int, 2000, 40(12):1275
[10]	Choi W, Matsuura H, Tsukihashi F. Changing behavior of non-metallic inclusions in solid iron deoxidized by Al-Ti addition during heating at 1473 K. ISIJ Int, 2011, 51(12):1951
[13]	Qin X Z, Guo J T, Yuan C, et al. Decomposition of primary MC carbide and its effects on the fracture behaviors of a cast Ni-base superalloy. Mater Sci Eng A, 2008, 485(1):74
[15]	Narita K. Physical chemistry of the groups IVa (Ti, Zr), Va (V, Nb, Ta) and the rare earth elements in steel. Trans ISIJ, 1975, 15(3):145
[16]	Tamura M, Iida H, Esaka H, et al. Solubility product of VN in austenite of high Cr heat resistant steel. ISIJ Int, 2003, 43(11):1807
[17]	Pavlina E J, Speer J G, Van Tyne C J. Equilibrium solubility products of molybdenum carbide and tungsten carbide in iron. Scripta Mater, 2012, 66(5):243
[18]	Bratberg J, Frisk K. A thermodynamic analysis of the Mo-V and Mo-V-C system. Calphad, 2002, 26(3):459
[19]	Inoue K, Ishikawa N, Ohnuma I, et al. Calculation of phase equilibria between austenite and (Nb, Ti, V)(C, N) in microalloyed steels. ISIJ Int, 2001, 41(2):175
[20]	Zou H L, Kirkaldy J S. Carbonitride precipitate growth in titanium/niobium microalloyed steels. Metall Trans A, 1991, 22(7):1511
[21]	Sharma R C, Lakshmanan V K, Kirkaldy J S. Solubility of niobium carbide and niobium carbonitride in alloyed austenite and ferrite. Metall Trans A, 1984, 15(3):545
