基于XFEM的巖體卸荷過程裂紋起裂擴展規律研究

鄧青林; 趙國彥; 譚彪; 鄒玉良; 李夕兵

doi:10.13374/j.issn2095-9389.2017.10.002

基于XFEM的巖體卸荷過程裂紋起裂擴展規律研究

doi: 10.13374/j.issn2095-9389.2017.10.002

1) 核工業西南勘察設計研究院有限公司, 成都 610061
2) 中南大學資源與安全工程學院, 長沙 410083
3) 同濟大學土木工程學院, 上海 200092

基金項目:

國家自然科學基金面上資助項目(51374244)

詳細信息

中圖分類號: TU457
計量
- 文章訪問數: 877
- HTML全文瀏覽量: 319
- PDF下載量: 16
- 被引次數: 0
出版歷程
- 收稿日期: 2016-11-02

Study on crack initiation and propagation in rock mass during unloading based on XFEM

1) Southwest Geotechnical & Design Institute of China Nuclear Industry Co. Ltd., Chengdu 610061, China
2) School of Resources and Safety Engineering, Central South University, Changsha 410083, China
3) School of Civil Engineering, Tongji University, Shanghai 200092, China

摘要

摘要: 地下和邊坡工程開挖常涉及巖體卸荷問題,采用ABAQUS軟件中的擴展有限單元法(extended finite element method,XFEM)對開挖卸荷過程巖體內部裂紋的起裂擴展進行了模擬,通過計算裂紋尖端應力強度因子研究了其起裂特征,并探討了起裂影響因素,通過記錄裂紋擴展形態研究了其動態演化模式.結果表明,卸荷過程中卸荷速率越快,裂紋長度越長,傾角越大,其起裂越容易;并且裂紋面受到的正應力不斷減小,剪應力不斷增大,裂紋擴展主要由剪應力控制,這與理論分析結果一致.裂紋最終擴展演化形態也與物理試驗相近,充分表明運用擴展有限單元法研究巖體裂紋問題的可靠性.
- 巖體卸荷 /
- 裂紋 /
- 起裂擴展 /
- 擴展有限單元法
Abstract: Rock-mass unloading often occurs during underground and slope engineering excavations. Here, rock-mass crack initiation and propagation during the excavation unloading progress was simulated using the extended finite element method (XFEM) in ABAQUS. Crack propagation and its influencing factors were studied and discussed after calculating the stress intensity factors at the crack tips, and by recording the crack's shape a dynamic evolution model was produced. The results show that the faster the unloading rate,the longer the crack,and the greater the crack dip angle, the easier the crack initiates. The normal stress on a crack surface decreases while shear stress increases during unloading, and that crack propagation is mainly controlled by shear stress. This is consistent with the theoretical analysis. The final shape of the modeled crack was also close to the result of the physical experiments, indicating the reliability of this study.
- rock-mass unloading /
- crack /
- initiation and propagation /
- extended finite element method

HTML全文

參考文獻(7)

[4]	Li Q Y, Dong L J, Li X B, et al. Effects of sonic speed on location accuracy of acoustic emission source in rocks. Trans Nonferrous Met Soc China, 2011, 21(12):2719
[7]	Zhuang X Y, Chun J W, Zhu H H. A comparative study on unfilled and filled crack propagation for rock-like brittle material. Theor Appl Fract Mech, 2014, 72:110
[8]	Yu T T. The extended finite element method (XFEM) for discontinuous rock masses. Eng Computation, 2011, 28(3):340
[9]	Deb D, Das K C. Extended finite element method for the analysis of discontinuities in rock masses. Geotech Geol Eng, 2010, 28(5):643
[10]	Belytschko T, Black T. Elastic crack growth in finite elements with minimal remeshing. Int J Num Method Eng, 1999, 45(5):601
[11]	Moes N, Dolbow J, Belytschko T. A finite element method for crack growth without remeshing. Int J Num Method Eng, 1999, 46(1):131
[15]	Ayhan A O. Mixed mode stress intensity factors for deflected and inclined corner cracks in finite-thickness plates. Int J Fatigue, 2007, 29(2):305
