    口環密封對多級離心泵濕轉子橫-軸雙向耦合動特性的影響

    周文杰 王孝軍 邱寧 王樂勤 高波

    周文杰, 王孝軍, 邱寧, 王樂勤, 高波. 口環密封對多級離心泵濕轉子橫-軸雙向耦合動特性的影響[J]. 工程科學學報, 2018, 40(12): 1540-1548. doi: 10.13374/j.issn2095-9389.2018.12.013
    引用本文: 周文杰, 王孝軍, 邱寧, 王樂勤, 高波. 口環密封對多級離心泵濕轉子橫-軸雙向耦合動特性的影響[J]. 工程科學學報, 2018, 40(12): 1540-1548. doi: 10.13374/j.issn2095-9389.2018.12.013
    ZHOU Wen-jie, WANG Xiao-jun, QIU Ning, WANG Le-qin, GAO Bo. Effect of annular seal on the lateral-axial bi-direction coupled dynamic characteristics of a multi-stage pump wet rotor[J]. Chinese Journal of Engineering, 2018, 40(12): 1540-1548. doi: 10.13374/j.issn2095-9389.2018.12.013
    Citation: ZHOU Wen-jie, WANG Xiao-jun, QIU Ning, WANG Le-qin, GAO Bo. Effect of annular seal on the lateral-axial bi-direction coupled dynamic characteristics of a multi-stage pump wet rotor[J]. Chinese Journal of Engineering, 2018, 40(12): 1540-1548. doi: 10.13374/j.issn2095-9389.2018.12.013

    口環密封對多級離心泵濕轉子橫-軸雙向耦合動特性的影響

    doi: 10.13374/j.issn2095-9389.2018.12.013
    基金項目:

    國家自然科學基金資助項目(51706087)

    詳細信息
    • 中圖分類號: TQ051.1

    Effect of annular seal on the lateral-axial bi-direction coupled dynamic characteristics of a multi-stage pump wet rotor

    • 摘要: 為探究口環密封對多級離心泵轉子橫-軸雙向耦合振動的影響,基于空間歐拉角變換及有限元法,建立了多級離心泵轉子系統葉輪和軸系的微分運動方程,在此基礎上,充分考慮口環流體激振力和多種軸向力的耦合作用,利用矩陣運算方法建立了多級離心泵濕轉子的橫-軸雙向耦合振動模型,并采用Newmark法對雙向耦合系統的瞬態動力學特性進行求解,重點研究了口環密封長度、壓差和間隙對系統耦合振動特性的變化規律,計算了不同密封參數下的流體激振力.計算結果表明,口環密封對轉子系統橫向振動的洛馬金效應隨著密封長度和壓差的增大以及間隙的減小愈發明顯,轉子系統的橫向穩態振動收斂速度快于軸向穩態振動的收斂速度,兩向瞬態振動的振動頻率呈現出完全不同的特性.此外,密封的流體激振力與密封長度呈現非線性變化關系,而與密封壓差和間隙呈現線性變化關系.



    • [2] Childs D W. Dynamic analysis of turbulent annular seals based on hirs' lubrication equation. J Lubr Technol, 1983, 105(3):429
      [3] Childs D W. Finite-length solutions for rotordynamic coefficients of turbulent annular seals. J Lubr Technol, 1983, 105(3):437
      [4] Childs D W. Rotordynamic moment coefficients for finite length turbulent seals//Proceedings of the IFTOMM Conference. Rome, 1982:371
      [5] Nelson C C, Nguyen D T. Analysis of eccentric annular incompressible seals:Part 1-a new solution using fast Fourier transforms for determining hydrodynamic force. J Tribol, 1988, 110(2):354
      [6] Nelson C C, Nguyen D T. Analysis of eccentric annular incompressible seals:Part 2-effects of eccentricity on rotordynamic coefficients. J Tribol, 1988, 110(2):361
      [7] Marscher W D. Analysis and test of multistage pump "wet" critical speeds. Tribol Trans, 1991, 34(3):445
      [8] Jiang Q L, Zhai L L, Wang L Q, et al. Fluid-structure interaction analysis of annular seals and rotor systems in multi-stage pumps. J Mech Sci Technol, 2013, 27(7):1893
      [9] Wang L Q, Zhou W J, Wei X S, et al. A coupling vibration model of multi-stage pump rotor system based on FEM. Mechanika, 2016, 22(1):31
      [10] American Petroleum Institute. ANSI/API Standard 610 Centrifugal Pumps for Petroleum, Petrochemical and Natural Gas Industries. Washington:API Publishing, 2010
      [11] Chen L W, Peng W K. The stability behavior of rotating composite shafts under axial compressive loads. Compos Struct, 1998, 41(3-4):253
      [12] Young T H, Shiau T N, Kuo Z H. Dynamic stability of rotorbearing systems subjected to random axial forces. J Sound Vib, 2007, 305(3):467
      [13] Yim K B, Yim J. Dynamic behavior of overhung rotors subjected to axial forces. Int J Precis Eng Manuf, 2012, 13(9):1575
      [14] Yim K B, Yim J T. Dynamic stability of a rotor with shear-flexible shaft under axial loads. J Mech Sci Technol, 2013, 27(2):359
      [16] Zou D L, Rao Z S, Ta N. Coupled longitudinal-transverse dynamics of a marine propulsion shafting under superharmonic resonances. J Sound Vib, 2015, 346:248
      [17] Zou D L, Liu L, Rao Z S, et al. Coupled longitudinal-transverse dynamics of a marine propulsion shafting under primary and internal resonances. J Sound Vib, 2016, 372:299
      [23] Gong R Z, Wang H J, Zhao J L, et al. Influence of clearance parameters on the rotor dynamic character of hydraulic turbine shaft system. Proc Inst Mech Eng C-J Mech Eng Sci, 2013, 228(2):262
